Crow Bar: Placed the midpoint of the main (horizontal) length of the crowbar on the origin. Needed to make a Sketch Plane for the Sweep hex cross section. The Plane was created parallel to the Right Plane and the through a sketch point from the Initial Outline sketch. If the initial outline should change, this Plane will update automatically. Download the part below to review the whole process.
Download: Crowbar Complexity: Basic Features used: Sweep, Draft, Slot
View all the Part Reviewer Tutorials here.
DraftSight Download: In conjunction with DraftSight, Dassault Systèmes’ 2D CAD product, the 2D drawing(.dwg) file of the Crow Bar tutorial is now available for download here.
